Slant txaj tshuab cuab yeej khiav du
Khoom Description
CNC inclined lathes feem ntau muaj peev xwm muab kev ua haujlwm zoo thaum lub sijhawm ua haujlwm. Qhov no feem ntau yog vim nws cov qauv tsim thiab kev ua kom zoo ntawm CNC system:
1. Cov qauv tsim: Lub txaj tsim ntawm CNC inclined tshuab dhos yog inclined, thiab cov qauv no yuav pab txhim kho lub rigidity thiab stability ntawm lub tshuab cuab yeej. Lub zog rigidity tuaj yeem txo kev vibration thiab deformation thaum lub sijhawm ua haujlwm, yog li txhim kho kev ua haujlwm raug thiab qhov zoo ntawm qhov chaw.
2. CNC system: CNC inclined tshuab dhos yog nruab nrog lub tshuab CNC siab heev uas tuaj yeem tswj tau qhov txav ntawm txhua qhov axis kom paub meej tias txoj kev ua haujlwm du thiab meej. Qhov kev tswj xyuas meej no tuaj yeem txo qhov nrawm nrawm thiab nrawm, uas yog qhov tsim nyog rau kev tswj hwm lub xeev kev ua haujlwm ruaj khov.
3. Cov cuab yeej thiab kev ua haujlwm tsis zoo: Kev xaiv cov cuab yeej tsim nyog thiab kev ua kom zoo ntawm kev ua haujlwm tsis zoo rau CNC inclined lathes kuj yog tus yuam sij rau kev ua haujlwm zoo. Kev xaiv cov cuab yeej zoo thiab cov kev ua haujlwm tsim nyog xws li pub ceev thiab ceev tuaj yeem txo kev vibration thiab suab nrov, thiab txhim kho kev ua haujlwm zoo thiab zoo.
Feem ntau, CNC inclined lathes ua lub luag haujlwm tseem ceeb hauv kev tsim khoom niaj hnub. Lawv muab kev ruaj khov, ua haujlwm tau zoo thiab muaj peev xwm ua tau zoo los ntawm kev tsim thiab tswj cov cuab yeej technology, thiab tsim nyog rau ntau yam kev ua haujlwm nyuaj.
| Specification | chav tsev | TSI 4550 | TCK4556-500 | TCK4556-1000 | TCK4572-1500 |
| Hla lub txaj | mm | 500 | 560 | 560 | 720 |
| Max machining ntev | mm | 360 | 350 | 350 | 620 |
| Swing hla lub swb | mm | 500 | 500 | 1000 | 1500 |
| Spindle lub cev muaj zog | KW | 11-15 | 11-15 | 30-37 | 30-37 |
| Txoj kab uas hla ntawm spindle los ntawm qhov | mm | 65 | 65 | 65 | 80 |
| Max spindle ceev | rpm ua | 50-4500/177 | 50-4500/177 | 50-4500/177 | 50-3500/145 |
| Lub kaum sab xis | deg | 45 | 45 | 45 | 45 |
| Clamping system | - | 8"/10" | 8"/10" | 15"/18"/21" | 15"/18"/21" |
| X-axis taug kev | Kw | 200 | 200 | 200 | 420 |
| Z-axis taug kev | mm | 550 | 560 | 1050 | 1550 |
| Tailstock lub tes tsho txoj kab uas hla / mus ncig | mm | 450 | 450 | 900 | 1650 |
| Lub tes tsho taper | MT | 5 | 5 | 6 | 6 |
| X / Z nrawm nrawm | m/min | 30/30 | 30/30 | 30/30 | 12/16 |
| Qhov ntev | mm | 2300*1600*1800 | 2300*1600*1800 | 5000*2400*2800 | 6000*2400*2800 |
| Tshuab hnyav (kwv yees) | Kg | 3600 | 3600 | 4500 | 5000 |
Siv tau machining qhov chaw
Ncej qhov chaw, disc qhov chaw, lub tes tsho, qhov tshwj xeeb zoo li tus, nkhaus qhov chaw, thiab lwm yam.
Qhia kom meej
CNC system
High-precision CNC system, yooj yim rau kev khiav lag luam, xaiv Siemens thiab FANUC systems.
Hydraulic chuck
Loj clamping ntau, ceev clamping ceev thiab siab precision.
Hydraulic cuab yeej tuav
Lub cuab yeej tuaj yeem hloov pauv ntawm ntau txoj haujlwm ntawm lub cuab yeej disc. Nws tuaj yeem tig sab laug thiab sab xis los hloov lub cuab yeej ntawm qhov xav tau, nrog cov cuab yeej hloov pauv ceev thiab ruaj khov thiab txhim khu kev qha.
Tshuab dhos tailstock
Tsis yooj yim rau kev tawg, ua tib zoo hauv av, kev kho mob ntau zaus quenching.
Peb qhov zoo dua
High-precision pob ntsia hlau
Imported high-precision pob ntsia hlau, siab precision thiab raug kis tau tus mob
Phau ntawv scraping
Txo qhov roughness ntawm qhov chaw thiab xyuas kom pom cov khoom raug
Saddle
Siv cov khoom siv high-density cam khwb cia hlau, tag nrho yog cam khwb cia hauv ib kauj ruam
Kev Tshawb Nrhiav Laser
Txo qhov ua yuam kev thiab ua tiav qhov chaw raug siab dua
Cov cuab yeej tshuab no yog siv rau ntau yam ncej thiab disc. Nws tuaj yeem tig ntau yam xov, arcs, cones thiab sab hauv thiab sab nraud ntawm lub cev rotating. Nws tuaj yeem ua tau raws li qhov xav tau ntawm kev kub ceev txiav ntawm cov hlau tsis muaj hlau thiab tsis yog hlau thiab tsim nyog rau kev lag luam xws li tsheb, maus taus, hluav taws xob, aerospace, thiab kev lag luam tub rog.
Qhov chaw ua haujlwm muaj ib txheej txheej rub lub hau thiab cov ntawv qhia kev ywj pheej nrog kev ntseeg siab.Qhov chaw tsis ua haujlwm muaj cov cuab yeej tiv thaiv nrog cov hneev taw me me.
Lub tiaj tiaj zawv zawg qhia kev tsheb nqaj hlau, siab-rigidity phau ntawv hauv qab phaj xauv, muaj kev ntseeg siab.
Qhov loj nti tshem tawm chaw nres nkoj teem ncaj nraim hauv qab lub ntxaiv yog yooj yim dua rau kev tawm thiab ntxuav ntawm cov txiav.
