Kitamura Kab rov tav
Kab rov tav machining chaw yog ib yam ntawm cov cuab yeej siv nrog siab rigidity thiab stability, uas yog dav siv nyob rau hauv lub machinery manufacturing kev lag luam. Cov txheej txheem tseem ceeb suav nrog tus qauv ntoo khaub lig zawv zawg rooj thiab ob txheej txheej rooj ua haujlwm. Cov qauv no tshwj xeeb tsim los muab kev ua tau zoo tshaj plaws thiab kev ua tau zoo.
Ua ntej ntawm tag nrho cov, tus ntoo khaub lig swb qauv yog ib qho tseem ceeb ntawm cov kab rov tav machining chaw. Nws muaj cov yam ntxwv ntawm qhov loj txiav quab yuam, kev loj hlob thiab ruaj khov, thiab tuaj yeem muab siab rigidity thiab zoo dynamic teb. Nyob rau hauv cov txheej txheem txiav, lub rigidity ntawm tus swb qauv ncaj qha cuam tshuam rau precision thiab nto zoo ntawm lub workpiece.
Thib ob, ob txheej txheej workbench kuj yog ib qho ntawm cov yam ntxwv ntawm kab rov tav machining chaw. Cov qauv no tuaj yeem txhim kho lub siab rigidity thiab ruaj khov ntawm lub tshuab cuab yeej, kom lub tshuab cuab yeej tseem tuaj yeem tuav lub xeev ua haujlwm ruaj khov thaum txiav ntawm kev kub ceev.
Txhawm rau txhawm rau txhim kho qhov nruj thiab ruaj khov ntawm lub tshuab cuab yeej, kev nthuav dav ntawm lub hauv paus thiab zawv zawg eeb tuaj yeem ua rau lub hauv paus khov kho ntawm lub tshuab cuab yeej thiab txhim kho kev ruaj ntseg ntawm lub tshuab cuab yeej thaum lub sij hawm txiav ceev. Kev tsim cov zawv zawg zawv zawg tuaj yeem ua kom zoo dua qhov kev faib tawm ntawm lub tshuab cuab yeej, txo qhov kev co tag nrho ntawm lub tshuab cuab yeej, thiab txhim kho qhov kev ua tau zoo ntawm lub tshuab cuab yeej. Lub rooj xauv quab yuam yog sib xws los xyuas kom meej lub rigidity ntawm lub rooj.
Cov qauv tshiab herringbone kem tuaj yeem txhim kho qhov kev ua tau zoo los tiv thaiv kev cuam tshuam ntawm lub tshuab cuab yeej thiab txhim kho qhov zoo li qub ntawm lub tshuab cuab yeej. Lub 'meter'-shaped reinforcement bar tuaj yeem txhim kho cov kabmob muaj peev xwm ntawm lub rooj, txhim kho lub rigidity thiab stability ntawm lub rooj.
Kev siv cov resin xuab zeb casting thiab honeycomb qauv, los ntawm ntau yam txheej txheem kev ntxhov siab, tuaj yeem txhim kho qhov tseeb thiab ruaj khov ntawm lub tshuab.
| Qauv | HMC1075 | HWM 1290 | HMC1395 |
| Lub rooj loj (mm) | 1300X600 | 1360X700 | 1400X700 |
| Tso cai siab tshaj plaws load (Kg) | 800 | 1000 | 1000 |
| X-axis taug kev (mm) | 1000 | 1200 | 1200 |
| Y-axis taug kev (mm) | 750 | 800 | 800 |
| Z-axis taug kev (mm) | 800 | 700 | 750 |
| T-qhov | 5-18-105 | 5-18-122 | 5-18-122 |
| Qhov deb ntawm spindle kawg lub ntsej muag mus rau lub rooj ua haujlwm (mm) | 115-915 | 180-880 | 168-918 |
| Qhov deb ntawm spindle center rau Z-axis rail nto (mm) | 110-860 | 140-940 | 260-1060 |
| Spindle taper | BT 50-150 | BT 50-190 | BT 50-190 |
| Spindle ceev (r / min) | 6000 | 6000 | 6000 |
| X / Y / Z nrawm nrawm (m / min) | 20/12/20 | 20/12/20 | 20/12/20 |
| Tshuab hnyav (Kg) | 8000 | 10000 | 10000 |
| Qauv | HMC1814 | HWM 500 | TIAB SA 630 |
| Lub rooj loj (mm) | 2000X900 | 500*500 | 630*630 |
| Tso cai siab tshaj plaws load (Kg) | 1600 | 600 | 950 |
| X-axis taug kev (mm) | 1800 | 600 | 1050 |
| Y-axis taug kev (mm) | 1280 | 360 | 750 |
| Z-axis taug kev (mm) | 900 | 450 | 900 |
| T-qhov | 5-22-165 | — | — |
| Qhov deb ntawm spindle kawg lub ntsej muag mus rau lub rooj ua haujlwm (mm) | 200-1100 | 150-850 | — |
| Qhov deb ntawm spindle center rau Z-axis rail nto (mm) | 140-1420 | 130-650 | 130-1030 |
| Spindle taper | BT 50-190 | BT 40-150 | BT 50-190 |
| Spindle ceev (r / min) | 6000 | 8000 | 6000 |
| X / Y / Z nrawm nrawm (m / min) | 18/12/18 | 20/12/20 | 20/12/20 |
| Tshuab hnyav (Kg) | 15000 | 8000 | 10000 |
