Siv Fanuc Robodrill
Vertical machining center yog cov cuab yeej tseem ceeb hauv kev ua haujlwm machining. Nws muaj cov yam ntxwv ntawm compact qauv tsim, me me hneev taw, ceev txav ceev thiab ua haujlwm siab. Qhov chaw machining no feem ntau yog tsim los ntawm lub zog muaj zog, uas tuaj yeem tiv taus siab dynamic loads los ntawm kev ua haujlwm siab ceev, ua kom ruaj khov thiab raug.
Nws cov qauv nruj heev ua kom muaj kev ruaj ntseg thiab raug raws li kev ua haujlwm siab, yog li txhim kho kev ua haujlwm zoo. Nws txoj siv tawv los yog tus tsim spindle ncaj qha tuaj yeem ua tau raws li kev xav tau sib txawv, xws li kev ua cov khoom lossis pwm tsim.
Cov qauv tsim ntawm ntsug machining chaw yog nruj, thiab nws cov rigidity siab thav duab thiab high precision kis tau tus mob system lav nws cov kev ua tau zoo. Nws cov thav duab nruj heev tuaj yeem nqus tau zoo thiab cuam tshuam qhov kev co thiab kev poob siab tsim tawm thaum lub sij hawm machining, kom ntseeg tau qhov tseeb machining thiab nto zoo. Cov kab ke sib kis tau txais cov cuab yeej ua haujlwm siab thiab cov kabmob kom ntseeg tau tias kev ruaj ntseg thiab raug ntawm cov txheej txheem kis tau tus mob.
Vertical machining chaw yog dav siv nyob rau hauv qhov chaw ua, pwm manufacturing, machinery manufacturing thiab lwm yam teb. Nws cov yam ntxwv ntawm kev ua haujlwm siab, precision thiab qhov chaw txuag ua rau nws muaj txoj haujlwm tseem ceeb hauv kev lag luam niaj hnub tsim. Nrog rau kev txhim kho txuas ntxiv ntawm thev naus laus zis, daim ntawv thov kev cia siab ntawm ntsug machining chaw yuav dav dua.
| Qauv | VWM 650 | VWM 840 | VWM 850 | VWM 855 | wb 966 |
| Lub rooj loj (mm) | 1000X400 | 1000X400 | 1000X500 | 1000X550 | 1100X550 |
| Tso cai siab tshaj plaws load (Kg) | 400 | 300 | 500 | 500 | 600 |
| X-axis taug kev (mm) | 650 | 800 | 800 | 800 | 900 |
| Y-axis taug kev (mm) | 400 | 400 | 500 | 550 | 600 |
| Z-axis taug kev (mm) | 550 | 550 | 500 | 550 | 600 |
| T-qhov | 3-18-120 | 3-18-140 | 5-18-108 | 5-18-90 | 5-18-100 |
| Qhov deb ntawm spindle center rau Z-axis rail nto (mm) | 485 | 445 | 552 | 590 | 663 |
| Qhov deb ntawm spindle kawg lub ntsej muag mus rau lub rooj ua haujlwm (mm) | 100-650 | 100-650 | 110-610 | 120-670 | 100-700 |
| Spindle taper | BT 40-120 | BT 40-120 | BT 40-140 | BT 40-150 | BT 40-150 |
| Spindle ceev (r / min) | 8000 | 8000 | 8000 | 8000 | 8000 |
| X / Y / Z nrawm nrawm (m / min) | 48/48/48 | 30/30/18 | 48/48/48 | 48/48/48 | 48/48/48 |
| Tshuab hnyav (Kg) | 3800 | 3200 | 5300 | 5500 | 5600 |
| Qauv | VMC1050 | VWM 1160 | VWM 1165 | VWM 1265 | VWM 1370 | VWM 1580 |
| Lub rooj loj (mm) | 1200X420 | 1200X600 | 1200X600 | 1200X600 | 1400X700 | 1700X800 |
| Tso cai siab tshaj plaws load (Kg) | 500 | 800 | 800 | 800 | 800 | 1500 |
| X-axis taug kev (mm) | 1000 | 1100 | 1100 | 1200 | 1300 | 1500 |
| Y-axis taug kev (mm) | 500 | 600 | 650 | 650 | 700 | 800 |
| Z-axis taug kev (mm) | 550 | 600 | 650 | 650 | 750 | 700 |
| T-qhov | 5-18-100 | 5-18-100 | 5-18-100 | 5-18-100 | 5-18-130 | 5-22-135 |
| Qhov deb ntawm spindle center rau Z-axis rail nto (mm) | 575 | 650 | 710 | 710 | 713 | 855 |
| Qhov deb ntawm spindle kawg lub ntsej muag mus rau lub rooj ua haujlwm (mm) | 100-650 | 120-720 | 120-720 | 120-770 | 120-870 | 160-860 |
| Spindle taper | BT 40-150 | BT 40-150 | BT 40-150 | BT 40-150 | BT 40-150 | BT 50-155 |
| Spindle ceev (r / min) | 8000 | 8000 | 8000 | 8000 | 8000 | 6000 |
| X / Y / Z nrawm nrawm (m / min) | 18/18/18 | 36/36/24 | 36/36/36 | 36/36/36 | 24/24/24 | 24/24/18 |
| Tshuab hnyav (Kg) | 5500 | 6500 | 6800 | 7000 | 8000 | 12000 |
