Vertical Machining Center VMC650
Khoom Taw Qhia
CNCLathe yog lub tshuab dhos ua haujlwm zoo uas tau txais koob meej hauv kev lag luam machining vim nws qhov tseeb thiab kev ua haujlwm zoo. Lub tshuab no yog automated tag nrho, ua rau nws haum rau siv nyob rau hauv loj ntau lawm thiab me me kev ua hauj lwm. Nws yog ib qho kev txhim khu kev qha rau cov neeg uas tab tom nrhiav kom kho lawv cov txheej txheem machining thiab nce cov khoom tsim tau.
Tsim thiab Nta
CNCLathe boasts ib tug intuitive neeg siv interface uas yuav siv tau rau kev pab cuam automated machining ua hauj lwm. Lub tshuab txiav cov cuab yeej siv los ntawm servo motors, uas ua kom muaj kev tswj xyuas qhov tseeb thiab qhov chaw. Lub tshuab dhos lub txaj yog tsim los ntawm cov hlau cam khwb cia zoo, ua kom muaj zog thiab ruaj khov rau kev ua haujlwm hnyav. Lub spindle tseem yog tsim los ntawm cov ntaub ntawv hwm thiab muaj kev kub ceev uas haum rau ntau yam kev ua haujlwm.
Lub tshuab tswj qhov system yog intuitive thiab yooj yim rau kev khiav lag luam, tso cai rau cov neeg siv los ua cov hauj lwm nyuaj machining yooj yim. Nws muaj ntau yam kev xaiv programming, suav nrog cov kab sib txuas thiab voj voj voog, ntau txoj xov hla, thiab cov cuab yeej them nyiaj. Thaum programmed, lub tshuab dhos tuaj yeem ua tiav ntau lub tshuab ua haujlwm tau txais, txo qhov xav tau ntawm tib neeg kev cuam tshuam.
Versatile Machining Peev Xwm
CNCLathe lub siab precision txiav thiab machining muaj peev xwm ua rau nws muaj ntau yam kev daws teeb meem rau ntau yam kev siv machining xws li tig, milling, drilling, thiab tho txawv. Lub tshuab no tuaj yeem tsim cov khoom sib txawv thiab cov khoom siv los ntawm cov khoom xws li steel, aluminium, thiab plastics.
CNC tswj system tso cai rau cov neeg siv los tsim cov contours thiab threads yooj yim, ua rau cov khoom tiav zoo. Lub tshuab spindle ceev tuaj yeem teem rau ntau yam ntawm RPMs, tso cai rau cov neeg siv los kho lawv cov kev txiav ceev ntawm ya raws raws li cov khoom siv machined.
Reliability thiab Durability
CNCLathe cov cav tov tau tsim los tiv thaiv kev nruj ntawm kev siv mus ntev, kev lag luam-scale siv. Lub tshuab dhos cov khoom thiab cov khoom siv yog cov khoom zoo, ua kom muaj kev ruaj khov thiab ua haujlwm ntev. Lub tshuab qhov tseeb thiab qhov tseeb raug tswj xyuas lub sijhawm, ua tsaug rau kev saib xyuas thiab kev pabcuam.
Xaus
Hauv cov ntsiab lus, CNCLathe yog lub tshuab dhos tshwj xeeb uas ua ke nrog precision, ntau yam, thiab kev ntseeg tau. Txawm hais tias koj tab tom nrhiav kom automate koj cov txheej txheem machining, ua tiav cov khoom tiav, lossis ua kom cov khoom tsim tau zoo, lub tshuab no yog qhov kev daws teeb meem zoo rau koj cov kev xav tau. Nrog nws cov intuitive tswj thiab ntau yam machining peev xwm, CNCLathe yog ib qho tseem ceeb ntxiv rau tej machining lag luam.
| Qauv | VWM 650 | VWM 840 | VWM 850 | VWM 855 | wb 966 |
| Lub rooj loj (mm) | 1000X400 | 1000X400 | 1000X500 | 1000X550 | 1100X550 |
| Tso cai siab tshaj plaws load (Kg) | 400 | 300 | 500 | 500 | 600 |
| X-axis taug kev (mm) | 650 | 800 | 800 | 800 | 900 |
| Y-axis taug kev (mm) | 400 | 400 | 500 | 550 | 600 |
| Z-axis taug kev (mm) | 550 | 550 | 500 | 550 | 600 |
| T-qhov | 3-18-120 | 3-18-140 | 5-18-108 | 5-18-90 | 5-18-100 |
| Qhov deb ntawm spindle center rau Z-axis rail nto (mm) | 485 | 445 | 552 | 590 | 663 |
| Qhov deb ntawm spindle kawg lub ntsej muag mus rau lub rooj ua haujlwm (mm) | 100-650 | 100-650 | 110-610 | 120-670 | 100-700 |
| Spindle taper | BT 40-120 | BT 40-120 | BT 40-140 | BT 40-150 | BT 40-150 |
| Spindle ceev (r / min) | 8000 | 8000 | 8000 | 8000 | 8000 |
| X / Y / Z nrawm nrawm (m / min) | 48/48/48 | 30/30/18 | 48/48/48 | 48/48/48 | 48/48/48 |
| Tshuab hnyav (Kg) | 3800 | 3200 | 5300 | 5500 | 5600 |
| Qauv | VMC1050 | VWM 1160 | VWM 1165 | VWM 1265 | VWM 1370 | VWM 1580 |
| Lub rooj loj (mm) | 1200X420 | 1200X600 | 1200X600 | 1200X600 | 1400X700 | 1700X800 |
| Tso cai siab tshaj plaws load (Kg) | 500 | 800 | 800 | 800 | 800 | 1500 |
| X-axis taug kev (mm) | 1000 | 1100 | 1100 | 1200 | 1300 | 1500 |
| Y-axis taug kev (mm) | 500 | 600 | 650 | 650 | 700 | 800 |
| Z-axis taug kev (mm) | 550 | 600 | 650 | 650 | 750 | 700 |
| T-qhov | 5-18-100 | 5-18-100 | 5-18-100 | 5-18-100 | 5-18-130 | 5-22-135 |
| Qhov deb ntawm spindle center rau Z-axis rail nto (mm) | 575 | 650 | 710 | 710 | 713 | 855 |
| Qhov deb ntawm spindle kawg lub ntsej muag mus rau lub rooj ua haujlwm (mm) | 100-650 | 120-720 | 120-720 | 120-770 | 120-870 | 160-860 |
| Spindle taper | BT 40-150 | BT 40-150 | BT 40-150 | BT 40-150 | BT 40-150 | BT 50-155 |
| Spindle ceev (r / min) | 8000 | 8000 | 8000 | 8000 | 8000 | 6000 |
| X / Y / Z nrawm nrawm (m / min) | 18/18/18 | 36/36/24 | 36/36/36 | 36/36/36 | 24/24/24 | 24/24/18 |
| Tshuab hnyav (Kg) | 5500 | 6500 | 6800 | 7000 | 8000 | 12000 |
Cim npe nrov: Vertical machining center VMC650, Tuam Tshoj ntsug machining chaw VMC650 manufacturers, lwm tus neeg, Hoobkas
