High-precision pwm hnyav txiav ua chaw
High-precision heavy-duty txiav thiab high-power machining chaw rau pwm yog cov khoom siab heev hauv CNC tshuab cuab yeej kev lag luam hauv xyoo tas los. Lub tshuab cuab yeej siv cov cuab yeej ua haujlwm siab thiab kev tswj xyuas siab heev kom tau raws li qhov xav tau ntawm kev ua haujlwm siab, kev ua haujlwm siab thiab kev ntseeg siab. Nws yog dav siv nyob rau hauv pwm manufacturing, aviation manufacturing, tsheb manufacturing thiab lwm yam teb.
Ua ntej ntawm tag nrho cov, los ntawm kev xav ntawm kev ua kom raug, lub high-power machining chaw rau hnyav txiav ntawm high-precision pwm muaj cov neeg siab heev thiab muaj peev xwm ua tau raws li high-precision ua cov kev xav tau ntawm complex pwm. Secondly, nyob rau hauv cov nqe lus ntawm kev ua hauj lwm efficiency, lub high-power machining chaw rau hnyav txiav ntawm high-precision pwm muaj zog ua muaj peev xwm, siab ua efficiency, thiab zoo heev txhim kho efficiency.
Tsis tas li ntawd, lub rooj ua haujlwm ntawm high-precision heavy-duty txiav high-power machining chaw tuaj yeem ua tiav kev sib hloov ceev thiab muaj peev xwm thauj khoom loj, uas tso cai rau lub tshuab cuab yeej ua kom tiav cov txheej txheem ua haujlwm loj. Tsis tas li ntawd, cov cuab yeej siv tshuab kuj muaj kev ruaj ntseg zoo thiab kev ntseeg siab, uas tuaj yeem ua kom ruaj khov ntawm lub tshuab cuab yeej siv tau ntev.
Thaum ua tiav high precision thiab efficiency, lub high-power machining chaw rau hnyav txiav ntawm high-precision pwm kuj txhawb automated ua. Nws preprocessing software tuaj yeem paub txog kev ua haujlwm tsis siv neeg thiab txhim kho kev tsim khoom zoo heev. Yog hais tias ua ke nrog robotic caj npab los yog lwm yam khoom siv automated, tag nrho tsis siv neeg ntau lawm kab ua tiav, zoo heev txhim kho kab ntau lawm efficiency.
Nyob rau hauv luv luv, high-precision pwm hnyav txiav thiab high-power machining chaw yog cov neeg sawv cev khoom nyob rau hauv lub teb ntawm CNC tshuab cuab yeej nyob rau hauv xyoo tas los. Nws cov yam ntxwv ntawm high precision, high efficiency thiab siab stability endow nws nrog tsis tshua muaj nqi siab thiab dav daim ntawv thov prospects.
| Specifications | chav tsev | VWM 650 | VWM 850 | VWM 855 | VWM 1050 | VWM 1160 | VWM 1370 | VWM 1580 |
| Rooj loj 工作台尺寸 |
mm | 900x400 | 1000X500 | 1000x550 | 1000x530 | 1200x600 | 1500x700 | 1700x800 |
| Table siab tshaj load 工作台最大承重 |
kg | 350 | 500 | 500 | 600 | 1000 | 900 | 1500 |
| X / Y / Z axis taug kev X/Y/Z轴坐标行程 |
mm | 650x400x500 | 800x500x500 | 800x550x550 | 1000x500x600 | 1100x600x600 | 1300x700x700 | 1500x800x700 |
| Kev ncua deb ntawm spindle center thiab kem 主轴中心线至立柱正面导轨距离 |
mm | 476 | 552 | 590 | 580 | 650 | 752 | 871 |
| Kev ncua deb ntawm spindle endface thiab worktable nto 主轴端面至工作台上平面距离 |
mm | 100-600 | 120-670 | 120-670 | 140-740 | 120-720 | 150-850 | 150-900 |
| X/Y/Z Max. pub ceev X/Y/Z最大进给速度 |
mm/min | 10000 | 10000 | 10000 | 10000 | 10000 | 8000 | 10000 |
| X/Y/Z Max. Kev nrawm nrawm X/Y/Z最大快移速度 |
m/min | 32/32/30 | 32/32/30 | 32/32/30 | 32/32/24 | 32/32/30 | 20/20/15 | 20/20/16 |
| spindle ceev 主轴转速 |
r / min | 8000 | 8000 | 8000 | 8000 | 8000 | 8000 | 8000 |
| spindle taper 主轴锥孔 |
hom | BT40 | BT40 | BT40 | BT40 | BT40 | BT40 | BT50 |
| Spindle lub cev muaj zog 主轴电机功率 |
kW | 5.5/7.5 | 7.5/11 | 7.5/11 | 7.5/11 | 11/15 | 11/15 | 15/18 |
| X / Y / Z axis servo lub cev muaj zog X/Y/Z轴伺服电机功率 |
kW | 2.6/2.6/2.8 | 3.9/3.9/3.6 | 3.9/3.9/3.6 | 3.9/3.9/3.6 | 4/4/5 | 4/4/5 | 4.5/4.5/4.5 |
| X / Y / Z lub cev muaj zog txuas X/Y/Z电机连接方式 |
Ncaj qha 直联 |
Ncaj qha 直联 |
Ncaj qha 直联 |
Ncaj qha 直联 |
Ncaj qha 直接 |
Ncaj qha 直接 |
Ncaj qha 直接 |
|
| X/Y/Z Guide way type X/Y/Z导轨类型 |
Kab rail 线轨 |
Kab rail 线轨 |
Kab rail 线轨 |
Kab rail 线轨 |
peb kab 3线 |
Ob kab thiab ib txoj kab nyuaj 2线一硬 |
Ob kab thiab ib txoj kab nyuaj 2线一硬 |
|
| T qhov 工作台T型槽 |
mm | 3-18x125 | 5-18x90 | 5-18x90 | 5-18x90 | 5-18x100 | 5-18x145 | 5-22x145 |
| Rov ua dua qhov tseeb 重复定位精度 |
mm | ±0.004 | ±0.004 | ±0.004 | ±0.004 | ±0.005 | ±0.005 | ±0.005 |
| Cov cuab yeej magazine 刀库形式 |
Lub kaus mom hom / disc hom 斗笠式/圆盘式 |
Lub kaus mom hom / disc hom 斗笠式/圆盘式 |
hom disc 圆盘式 |
hom disc 圆盘式 |
hom disc 圆盘式 |
hom disc 圆盘式 |
hom disc 圆盘式 |
|
| Tool muaj peev xwm 刀库容量 |
16T/16T | 24T | 24T | 24T | 24T | 24T | 24T | |
| Qhov siab tshaj qhov ntsuas qhov hnyav 最大刀具重量 |
kg | 7 | 8 | 8 | 8 | 8 | 8 | 15 |
| Max. cuab tam ntev 最大刀具长度 |
mm | 250/300 | 250/300 | 300 | 250/300 | 300 | 300 | 300 |
| Hluav taws xob muaj peev xwm 电气总容量 |
kVA ua | 10 | 15 | 15 | 15 | 18 | 22 | 30 |
| Tshuab dimension (LxWxH) 机床尺寸(长x宽x高) |
mm | 2300x2000x2300 | 2600x2380x2700 | 2600x2380x2700 | 3200x2420x2400 | 3100x2490x2380 | 3600x3000x2700 | 4260x3545x3200 |
| Net. hnyav (kwv yees) 机床重量(约) |
kg | 4500 | 5000 | 5000 | 6000 | 7000 | 11000 | 12000 |
